Ikelite's UW-Housing for Canon 7D MKII are extremely popular and has been completely re-designed from the ground up to include all of their latest improvements. Featuring the new Dry Lock (DL) port system. Vacuum valve are included. TTL circuitry sold separately. Lens port and zoom gear sold separately.
More information
Lens Ports
The single most important upgrade is our long awaited new Dry Lock (DL) port system. This exciting new system is even more robust and even easier to assembly than our time-tested Four Lock (FL) system. The new ports are lighter and more adaptable, and can accommodate extremely large diameter lenses with ease. If you're considering shooting professional quality lenses like the Canon EF 16-35mm Type II/III or the Canon EF 11-24mm, then the DL system is essential.
Most popular zoom lenses and select lens focus rings can be engaged using a simple yet effective gearing system that puts adjustment right at your fingertips. A large, soft-touch lobed knob on the side of the housing makes fine tuned adjustments a breeze. Zoom and focus gears differ depending on which lens you are using.
Vacuum System
The included vacuum valve allows you to vacuum test the housing to check for leaks prior to putting your expensive equipment in the water. Combined with a full view of the camera and o-ring seal through the back of the housing, there is no greater assurance that your gear will be safe. Our signature open-groove design suspends the rear o-ring in a natural position that is easier to maintain and more reliable than forcing the o-ring into a channel. Use of the vacuum valve requires a compatible Vacuum Pump with Gauge # 47011, sold separately.
TTL Exposure
Install optional CT1K Canon TTL Kit # 46070 for automatic TTL exposure with compatible Ikelite DS-model Strobes. Ikelite DS-model strobes may be used with this system without the Canon TTL Kit installed, but will not provide TTL exposure. Single Strobe Cord # 4103.51 / Dual Strobe Cord # 4103.52
Non-Ikelite Strobes
SEA&SEA, INON, and Nikonos strobes with an electrical connection can be triggered in manual exposure modes using an electrical sync cord. Strobes without an electrical sync cord connection cannot be attached to this system unless slaved off of a hard-wired strobe. Single INON or SEA&SEA Strobe Cord # 4118.1 / Dual INON or SEA&SEA Strobe Cord # 4118.2 / Single Nikonos SB Strobe Cord # 4116.31 / Dual Nikonos SB Strobe Cord # 4116.32
Specifications
60m depth rating
1/4-20 thread base mounts with 3.5" spacing
Near neutral buoyancy in fresh water
Actual buoyancy varies depending on choice of lens and port
Weight 2.2 kg not including tray + handles
Dimensions 241 x 180 x 165 mm including projections
